LeoXZ XGT Pro

FEATURE

1. 295mm polyurethane grip, produced by high-precision molds, has a special coating on its surface, and its delicate texture satisfies various driving needs.
2. The back cover and paddles are processed using CNC technology and coated with black anodizing to achieve optimal appearance and lasting durability.
3. The front panel and paddles are made of 4mm 3K carbon fiber with high-end textured coating.
4. 9+14+4RGB LEDs that can be customized through SimHub.
5. 0.96inch IPS screen with a resolution of 160x80 pixels and a 60fps refresh rate, and its dashboard can be customized through SimHub.
6. 14 RGB buttons with 500g of actuation force, 2 Multi-directional joystick with integrated encoders and 4 push-button encoders, 2 thumb knob
7. It comes with a standard magnetic shifter paddle, and additional clutch paddles are available as options.
8. The clutch paddles can be set to bite point mode, axis mode.
9. All paddles use non-contact Hall sensors for long-lasting durability.
10. 70mm diameter QR mounting hole.
11. It can be connected to Leoxz Fanatec QR through the QR cable interface to unlock Fanatec base torque.
12. Optional powered QR for Fanatec, Simagic, and Moza.
13. Fanatec mode for compatibility with PS4/5 on Fanatec bases. Supports access to the Fanatec Tuning Menu for adjusting base settings(Leoxz has only tested it on Fanatec DD Pro-PS Mode).
14. Low latency 2.4G wireless functionality(need to purchase XGT 2.4G Link separately as a USB receiver).
15. Equipped with an industrial-grade GX12 threaded USB interface and a USB double-twisted cable with nylon tensile resistance, subjected to 100,000 cycles of cable twisting tests.

SOFTWARE

SimHub and SimBridge

SimHub for getting telemetry data

SimBridge is used to receive SimHub data and send it to XGT

PACKAGING

Dimensions (LxWxH): 33cm x 19cm x 14cm

Weight: 1.5kg

INCLUDED

XGT Pro Steering Wheel
USB-GX12 Cable
Custom Stickers
Nylon Tweezers

NOTES

1. The steering wheel can only be used in sim racing
2. For USB power input, the maximum voltage is 5V. For QR power input, the maximum voltage is 12V. Exceeding these maximum voltage limits may result in damage to the steering wheel.
3. The free version of Simhub only outputs data at 10 frame rate, you need to purchase an additional license to have 60 frame rate.
4. The SimHub dashboard is only effective when connected via USB. When using a 2.4G wireless connection, only the built-in dashboard for gear and speed is available.
5. When using the wireless functionality of the steering wheel, it is advisable to place the wireless receiver within approximately 1 meter or closer to the steering wheel. Otherwise, it may result in a decrease in wireless speed.
6. For bases that may have noticeable EMI issues, such as the Fanatec DD1/2, the optimal choice is to connect the steering wheel using an externally powered USB hub, along with a USB isolator. Additionally, it is recommended to ensure that the DD1/2 has an additional grounding cable (https://fanatec.com/us-en/faq/details/id/72).
